CT Series Liquid Cartridge Filter/Strainer

  • Product introduction
Cartridge Filter/Strainer is designed with filter cartridge which serves as the filter element. It applies to precision filtration of fluid and removal of micro-amount tiny impurities contained in the fluid, featuring high precision, high efficiency and large pollutant-holding capacity. CT Filter is matched with multiple types of high-performance filter cartridges and can therefore fulfill various ordinary and special requirements on precision filtration.

CT Filter/Strainer can fall into 4 subseries:

CTT series: the economical filter is designed with clamp-type roof cover which can facilitate starting up and operation. It applies to ordinary filtration with small flux and low pressure;

CTS series: the clamp-type closed-form structure of the roof cover with quick-open design can fulfill strict application requirements, featuring reliable performance and strong durability;

CTM series: it is exclusively designed for application occasions with large flux, high precision and large pollutant-holding capacity. It is designed with both horizontal and vertical type, featuring large flux, compact structure and convenient replacement;

CTR series: the edible-class design features thorough sanitation and allows for complete dismantlement for cleaning. With edible-class polished inner surface, the filter applies to food and beverage and pharmaceutical industry.

Application area

Applicable fields: Fine chemical engineering, water treatment system, paper making, automatic industry, petrochemical engineering, mechanical processing, paint, electrics etc.
Applicable liquids: Extremely wide applicability scope; applicable to various fluids containing micro amount of impurities.
Main filtration function: Removing tiny particles, purifying liquid and protecting key equipment.
Filter type: Particulate filtration, using discarded filter material, manual replacement.

Specifications
Sub-series CTR/CTS/CTM/CTT
Optional filter Folding filter, meltblown filter, wire wound filter, metal filter high flow filter
Optional precision(u m) 0.05-200
Filter length (inches) 1020304060
Number of individual filter elements 1-200
Shell material 304316LCS
Applicable viscosity(cp)  1-500
Design pressure(MPa)  0.6-1.0 other pressures can be customized

Field case
